Low Relaxation 7 Wire 12.7mm Steel Strand for Prestressed Concrete

Low Relaxation 7 Wire 12.7mm Steel Strand for Prestressed Concrete
Low Relaxation 7 Wire 12.7mm Steel Strand for Prestressed Concrete
Low Relaxation 7 Wire 12.7mm Steel Strand for Prestressed ConcreteLow Relaxation 7 Wire 12.7mm Steel Strand for Prestressed ConcreteLow Relaxation 7 Wire 12.7mm Steel Strand for Prestressed ConcreteLow Relaxation 7 Wire 12.7mm Steel Strand for Prestressed ConcreteLow Relaxation 7 Wire 12.7mm Steel Strand for Prestressed Concrete
CategoriesPc strand
AlbumView larger image
BrandChunpeng
ModelChunpeng PC Strand
Tensile strength1460-1860Mpa
Diameter6.5MM-21.8MM
CertificationBV/ISO9001:2000/ SGS
Structure1*3/1*7/1*19
Grade270(1860Mpa)
UsageConstruction Materilals
PackageRoll Packing
StandardASTM A416, BS5896, EN10138
Material77B/82B
Product nameLow Relaxation 7 Wire 12.7mm Steel Strand for Pre
FOB portTianjin
Terms of PaymentL/C, D/A, D/P, T/T
Download DOC
Update Time2020-05-28
Detail Information

 Low Relaxation  7 Wire 12.7mm Steel Strand for Prestressed Concrete

                                    High Quality !!1*7 12.7mm Prestressed Concrete Strand for Crane Beam

Sophie  chen


Email: sophiechen@pcstrand.cc

Tel: 0086-22-65833507

Cellphone:0086138200626419(whatsapp)




1. Item           Low Relaxation  7 Wire 12.7mm Steel Strand for Prestressed Concrete
2. Specification

1 x 7 wire, 1x2 wire,1x3 wire,1x19 wire

9.53mm, 12.7mm, 15.2mm, 15.7mm, 17.8mm, 21.8mm

3. AppliacationWidely Used for any aqueduct, viaduct, bridge, tunnel and railway construction
4. CertificateISO9001:2000  SGS BV
5. StandardASTM A416, BS5896, JIS G3536, GB/T5223, EN10138,PREN6138
6. Output500, 000 ton/year
7. FeaturesHigh tensile, low relaxtion
8. TwistLeft and right hand lay
9. Factory Test

Norminal diameter, breaking force, elongation at rupture, tensile strenght, stress relaxastion

property, relax value at 1000h

10. PackingStandard Export Package (Wrapped by steel strips, waterproof cloth sheet, wooden pallet)
11. OriginalTianjin, China
12.  PaymentT/T, LC
13.  Delivery Timein 10 days after we receive your deposit or LC



High Quality !!1*7 12.7mm Prestressed Concrete Strand for Crane Beam


High Quality !!1*7 12.7mm Prestressed Concrete Strand for Crane Beam
High Quality !!1*7 12.7mm Prestressed Concrete Strand for Crane Beam

Inner Diameter: 760mm
Outside Diameter:1400mm Max
Coil’s width: 760mm
Coil’s Weight: 2500~3500 kg
We use vapors corrosion inhibiting technology on export anti-rust packing. Out side of the coil has 3 wraps.

There are two wooden pallets on the bottom of the coil. The coil is eye to sky in the container.







High Quality !!1*7 12.7mm Prestressed Concrete Strand for Crane Beam
